COMPONENTS
Pursuit & Time Trial
An advanced base bar system engineered to maximize aerodynamic performance. Its refined profile significantly reduces frontal area while providing exceptional ergonomic adjustability.
Operational Flexibility
A stack spacer system with up to 45 mm of height adjustment, 30° angle spacers, and four interchangeable grip options allow riders to achieve their ideal fit.
Wetsuit-Material Armrest
Armrest pads made from premium wetsuit material resist sweat and moisture while providing secure grip and lasting comfort during intense efforts.
Adjustable Armrest
The fully adjustable armrest system offers precise control of width, angle, and fore-aft position, helping every rider achieve an optimized aerodynamic position
GEOMETRY
- | - |
|---|---|
A. Basebar width | 360mm |
B. Basebar Drop | 53mm |
C. Extension Bar Length | 292mm |
D. Extension Bar Degree | 135° |
E. Extension Bar Back and forward Adjustment range | 20mm (Rail type) |
F. Extension Bar Center to Center | 98, 135mm (Slot type) |
G. Outside pad width | 195mm (Narrowest),
295.5mm (Largest) |
Angle Spacer | 5°-25°(2bolt type) |
Side angle spacer | 0°-8° |
Grip kinds | 4 types |
Size | One size Only |
SPECIFICATIONS
WINACT Carbon System, 380 g (Base Bar),
2 types of armrest, 4 types of grip,
Extension bar and pad distance adjustable,
Extension bar front and rear 20mm adjustable,
Extension bar angle 5-25 degree adjustable.
*UCI Legal (Including 2027 Rule Changes)
